SGS SGS 36617
SGS 36617 Z-Carb-HTA ZH1CR Center Cutting High Performance Regular Length Positive Rake Single End Mill, 1/2 in Dia Cutter, 0.03 in Corner Radius, 1-1/4 in Length of Cut, 4 Flutes, 1/2 in Dia Shank, 3-1/4 in OAL, AlTiN Coated
Invoice description:
End Mill 1/2 X 1-1/4 X 3-1/4,.030cr Altin
UPC: 691781366173
UNSPSC:
27112803
Manufacturer PN: 36617
$134.66 EA
Factory OrderEstimated to ship in 7 days
SGS End Mill, Center Cutting High Performance Regular Length Positive Rake Single, Series: Z-Carb-HTA ZH1CR, 1/2 in Cutter Dia, 0.03 in Corner Radius, 3-1/4 in Overall Length, 1-1/4 in Length of Cut, 4 Flutes, Right Spiral Flute, 1/2 in Shank Dia, Right Hand Cutting, 38 to 41 deg Helix Angle, Weldon Flat Shank, 2 in Shank Length, Solid Carbide, AlTiN Coated
Features
- The original Z-carb design with an enhanced core and higher helix suited for the demands of high temperature alloys
- Unequal helix design aids in damaging harmonics by changing the angle at which each cutting edge enters and exits the material
- Unequal flute spacing helps to disrupt the rhythmic pattern created by the cutting edge helping to suppress damaging harmonics
- Optimal material removal rates through increased feed and depths of cut for difficult to machine materials
- Enhanced corner geometry with tight tolerance corner radii
- Recommended for materials
- Suitable for steel, stainless steel, cast iron, high temperature alloy, titanium alloy and hardened steel
Specifications
ApplicationAerospace, Automotive, Castings and Foundries, General Engineering, Medical, Mold and Die and Power Generation
Corner Radius0.03 in
Cutter Diameter1/2 in
Cutting DirectionRight Hand
FinishAlTiN Coated
Flute TypeRight Spiral
Helix Angle38 to 41 deg
Length of Cut1-1/4 in
MaterialSolid Carbide
Number of Flutes4
Overall Length3-1/4 in
SeriesZ-Carb-HTA ZH1CR
Shank Diameter1/2 in
Shank Length2 in
Shank TypeWeldon Flat
TypeCenter Cutting High Performance Regular Length Positive Rake Single
Additional Information
Country of OriginUS
Sds
