SGS SGS 34815
SGS 34815 S-Carb 43CR Center Cutting High Performance Positive Rake Single End End Mill, 3/4 in Dia Cutter, 0.12 in Corner Radius, 1-5/8 in Length of Cut, 3 Flutes, 3/4 in Dia Shank, 4 in OAL, Uncoated
Invoice description:
End Mill 43c 3/4 .120r
UPC: 691781348155
UNSPSC:
27112803
Manufacturer PN: 34815
$294.40 EA
Factory OrderEstimated to ship in 14 days
SGS End Mill, Center Cutting High Performance Positive Rake Single End, Series: S-Carb 43CR, 3/4 in Diameter Cutter, 0.12 in Corner Radius, 4 in Overall Length, 1-5/8 in Length of Cut, 3 Flutes, Right Spiral Flute, 3/4 in Shank Diameter, Right Hand Cutting Direction, 38 deg Helix Angle, Straight Shank, 2-3/8 in Shank Length, Solid Carbide, Uncoated
Features
- Circular land allows for increased control at various speed and feed rates and reduces chatter
- Symmetrical end gashing for excellent balance at high speeds and aggressive plunging capability
- Open fluting for deep slotting and profiling
- Enhanced corner geometry with tight tolerance corner radii
- Recommended for materials
Specifications
ApplicationAerospace, Medical, Power Generation, Automotive, Castings, Foundries, General Engineering, Mold and Die
Corner Radius0.12 in
Cutter Diameter3/4 in
Cutting DirectionRight Hand
FinishUncoated
Flute TypeRight Spiral
Helix Angle38 deg
Length of Cut1-5/8 in
MaterialSolid Carbide
Number of Flutes3
Overall Length4 in
SeriesS-Carb 43CR
Shank Diameter3/4 in
Shank Length2-3/8 in
Shank TypeStraight
TypeCenter Cutting High Performance Positive Rake Single End
Additional Information
Country of OriginUS
Sds
