SGS SGS 32842
SGS 32842 S-Carb 43LC Center Cutting High Performance Long Reach Neck Positive Rake Single End End Mill, 1/2 in Dia Cutter, 0.12 in Corner Radius, 5/8 in Length of Cut, 3 Flutes, 1/2 in Dia Shank, 6 in OAL, TiB2 Coated
Factory Order
SGS End Mill, Center Cutting High Performance Long Reach Neck Positive Rake Single End, Series: S-Carb 43LC, 1/2 in Diameter Cutter, 0.12 in Corner Radius, 6 in Overall Length, 5/8 in Length of Cut, 3 Flutes, Right Spiral Flute, 1/2 in Shank Diameter, Right Hand Cutting Direction, 38 deg Helix Angle, Straight Shank, 5-3/8 in Shank Length, Solid Carbide, TiB2 Coated
Features
- Circular land allows for increased control at various speed and feed rates and reduces chatter
- Symmetrical end gashing for excellent balance at high speeds and aggressive plunging capability
- Open fluting for deep slotting and profiling
- Necked design with blended diameter transitions provide clearance to reach
- Enhanced corner geometry with tight tolerance corner radii
- Recommended for materials
Specifications
ApplicationAerospace, Medical, Power Generation, Automotive, Castings, Foundries, General Engineering, Mold and Die
Corner Radius0.12 in
Cutter Diameter1/2 in
Cutting DirectionRight Hand
FinishTiB2 Coated
Flute TypeRight Spiral
Helix Angle38 deg
Length of Cut5/8 in
MaterialSolid Carbide
Number of Flutes3
Overall Length6 in
SeriesS-Carb 43LC
Shank Diameter1/2 in
Shank Length5-3/8 in
Shank TypeStraight
TypeCenter Cutting High Performance Long Reach Neck Positive Rake Single End
