SGS SGS 32573
SGS 32573 V-Carb 55CR Center Cutting High Performance Positive Rake Single End End Mill, 3/8 in Dia Cutter, 0.03 in Corner Radius, 1 in Length of Cut, 5 Flutes, 3/8 in Dia Shank, 2-1/2 in OAL, AlTiN Coated
Invoice description:
End Mill 3/8 X 1 X 2-1/2 Oal .030cr,5-fl
UPC: 691781325736
UNSPSC:
27112803
Manufacturer PN: 32573
$69.88 EA
Factory OrderEstimated to ship in 7 days
SGS End Mill, Center Cutting High Performance Positive Rake Single End, Series: V-Carb 55CR, 3/8 in Diameter Cutter, 0.03 in Corner Radius, 2-1/2 in Overall Length, 1 in Length of Cut, 5 Flutes, Right Spiral Flute, 3/8 in Shank Diameter, Right Hand Cutting Direction, 45 deg Helix Angle, Straight Shank, 1-1/2 in Shank Length, Solid Carbide, AlTiN Coated
Features
- Unequal indexing, high helix and an ideal rake and relief combination for unmatched finishing capability
- The choice when peak finish quality is the requirement
- Enhanced corner geometry with tight tolerance corner radii
- Recommended for materials
Specifications
ApplicationAerospace, Medical, Power Generation, Automotive, Castings, Foundries, General Engineering, Mold and Die
Corner Radius0.03 in
Cutter Diameter3/8 in
Cutting DirectionRight Hand
FinishAlTiN Coated
Flute TypeRight Spiral
Helix Angle45 deg
Length of Cut1 in
MaterialSolid Carbide
Number of Flutes5
Overall Length2-1/2 in
SeriesV-Carb 55CR
Shank Diameter3/8 in
Shank Length1-1/2 in
Shank TypeStraight
TypeCenter Cutting High Performance Positive Rake Single End
Additional Information
Country of OriginUS
Sds
