GARR GARR 48415
GARR 48415 H45 Center Cutting High Feed High Performance Corner Radius End Mill, 5/16 in Dia Cutter, 0.02 in Corner Radius, 5/16 in Length of Cut, 4 Flutes, 5/16 in Dia Shank, 2-1/2 in OAL, AlTiN Coated
Invoice description:
Em 5/16x5/16locx5/16x 2-1/2 Cr0.02 4fl Altin Hp
Factory Order
GARR Corner Radius End Mill, Center Cutting High Feed High Performance, Series: H45, 5/16 in Diameter Cutter, 0.02 in Corner Radius, 2-1/2 in Overall Length, 5/16 in Length of Cut, 4 Flutes, Spiral Flute, 5/16 in Shank Diameter, Right Hand Cutting Direction, 45 deg Helix Angle, Solid Submicron Grain Carbide, AlTiN Coated
Features
- High performance tool for use on light axial depths of cut
Specifications
ApplicationFor die mold applications
Corner Radius0.02 in
Cutter Diameter5/16 in
Cutting DirectionRight Hand
FinishAlTiN Coated
Flute TypeSpiral
Helix Angle45 deg
Length of Cut5/16 in
MaterialSolid Submicron Grain Carbide
Number of Flutes4
Overall Length2-1/2 in
SeriesH45
Shank Diameter5/16 in
TypeCenter Cutting High Feed High Performance
Additional Information
Standards/ApprovalPROP65: This product can expose you to chemicals including cobalt, which is known to the State of California to cause cancer. For more information go towww.P65Warnings.ca.gov
Country of OriginUS
Specification Sheet
