Union Butterfield UTD 1010253
Union Butterfield 6007558 1508 General Purpose Union Butterfield Straight Flute Hand Tap, Right Hand Cutting, 1/2-13 Thread, H3 Thread Limit, Bottoming Chamfer, 3 Flutes, Bright, HSS
Invoice description:
1508 Bottoming Chamfer - 3 Utd 1010253 Ubc 1
Factory Order
Union Butterfield Union Butterfield Straight Flute Hand Tap, General Purpose, Series: 800, Measurement System: Imperial, UNC, 1/2-13, Bottoming Chamfer, 3 Flutes, HSS, Bright, Class of Fit: 3B, Right Hand Cutting, 1-21/32 in Thread Length, 3-3/8 in Overall Length, 0.367 in Shank Dia, Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials Material Application, H3 Thread Limit
Features
- Fewer flutes than standard, providing more space for chip evacuation and particularly when tapping holes greater than 1.5 tap Dia in depth
- A medium alloyed high speed steel that has good machinability and good performance
- HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications
Specifications
ApplicationFor through or blind hole applications
Chamfer TypeBottoming
Class of Fit3B
Cutting DirectionRight Hand
Finish/CoatingBright
MaterialHSS
Material ApplicationSteel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials
Measurement SystemImperial
Number of Flutes3
Overall Length3-3/8 in
Series1508
Shank Diameter0.367 in
Thread Length1-21/32 in
Thread LimitH3
Thread Size1/2-13
Thread StandardUNC
TypeGeneral Purpose
Additional Information
Standards/ApprovalANSI Specified|PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov|CSA Approved
Country of OriginUS
