Dormer UTD 080542
Dormer 5996301 QC21G General Purpose Heavy Duty Jobber Length Drill Bit, #42 Drill - Wire, 0.0935 in Drill - Decimal Inch, 135 deg Point, HSS, TiN Coated
Invoice description:
Ptd Jl 135sp Para Hss Ti N Utd 080542 Ptd Qc-
Factory Order
Dormer Jobber Length Drill Bit, General Purpose Heavy Duty, Series: QC21G, Imperial, #42 Drill - Wire, 0.0935 in Drill - Decimal Inch, 2-1/4 in Overall Length, 4XD Cutting Depth, 2 Flutes, Wide Land Parabolic Flute, 1-1/4 in Flute Length, 0.0935 in Shank, Straight Shank, 135 deg Point, Split/Self-Centering Point, Right Hand Cutting Direction, HSS Cutting Edge, No Through Coolant, HSS, TiN Coated, Gold, Applicable Materials: Alloy Steel, Aluminum, Aluminum Alloyed, Brass, Bronze, +/-Brass, Copper, Hardened/Tempered Steel, Lamellar Graphite, Magnesium, Magnetic Soft Steel, Plain Carbon Steel, Structural Steel/Case Carburizing Steel and Unalloyed
Features
- Parabolic flute design for efficient chip removal
- Allows greater drilling depths in one pass
- Low thrust design self-centering split point for easier penetration
- TiN coating increases wear resistance and improves tool life
Specifications
ApplicationFor general drilling applications
Applicable MaterialsAlloy Steel, Aluminum, Aluminum Alloyed, Brass, Bronze, +/-Brass, Copper, Hardened/Tempered Steel, Lamellar Graphite, Magnesium, Magnetic Soft Steel, Plain Carbon Steel, Structural Steel/Case Carburizing Steel and Unalloyed
ColorGold
Cutting Depth4XD
Cutting DirectionRight Hand
Cutting Edge MaterialHSS
Drill Diameter Measurement SystemImperial
Drill Size - Decimal Inch0.0935 in
Drill Size - Wire#42
FinishTiN Coated
Flute Length1-1/4 in
Flute TypeWide Land Parabolic
MaterialHSS
Number of Flutes2
Overall Length2-1/4 in
Point Angle135 deg
Point TypeSplit/Self-Centering
SeriesQC21G
Shank Size0.0935 in
Shank TypeStraight
Through Coolant (Yes/No)No
TypeGeneral Purpose Heavy Duty
Additional Information
Standards/ApprovalANSI Specified|CSA Approved
Country of OriginBR
