Dormer UTD 026175
Dormer 6001020 5ATS Jobber Drill, 17.5 mm Drill - Metric, 0.689 in Drill - Decimal Inch, Morse Taper Shank Taper, HSS
Invoice description:
Ptd Mts Din 118pt Hss Bl K Utd 026175 Ptd 5at
Factory Order
Dormer Jobber Drill, Series: 5ATS, Metric, Drill Size - Metric: 17.5 mm, Drill Size - Decimal Inch: 0.689 in, 228 mm Overall Length, Standard Spiral Flute, 130 mm Flute Length, Shank Taper Designation: Morse Taper, 118 deg Point, Right Hand Cutting, HSS Cutting Edge, Through Coolant (Yes/No): No, HSS, Steam Tempered, Black, Applicable Materials: Cast Iron, Cast Steel, High Temperature Alloys, Non-Ferrous Metals, Stainless Steel and Steel
Features
- Steam oxide for increased tool life and lubricity
- The A130 morse taper drill is especially suited for machine use and especially for column drilling machines
- Accurately ground from high quality high speed steel makes this a robust all rounder
- This specimen is steam relieving, which results in better retention of the cutting oil
Specifications
ApplicationFor column drilling machines
Applicable MaterialsCast Iron, Cast Steel, High Temperature Alloys, Non-Ferrous Metals, Stainless Steel and Steel
ColorBlack
Cutting DirectionRight Hand
Cutting Edge MaterialHSS
Drill Diameter Measurement SystemMetric
Drill Size - Decimal Inch0.689 in
Drill Size - Metric17.5 mm
FinishSteam Tempered
Flute Length130 mm
Flute TypeStandard Spiral
MaterialHSS
Overall Length228 mm
Point Angle118 deg
Series5ATS
Shank Taper DesignationMorse Taper
Through Coolant (Yes/No)No
Additional Information
Standards/ApprovalDIN 345
Country of OriginBR
