Dormer UTD 0030103

Dormer 5969689 A166 General Purpose Jobber Length Taper Shank Drill Bit, 30 mm Drill - Metric, 1.1811 in Drill - Decimal Inch, #3 Morse Taper Shank Taper, HSS HM

Invoice description: A166 Hss Mts Drills Carbide Tipped

UNSPSC: 23241639
Manufacturer PN: 5969689
$588.34 EA
Factory Order
QTY:


Dormer Taper Shank Drill Bit, General Purpose Jobber Length, Series: A166, Metric/Imperial, 30 mm Drill - Metric, 1.1811 in Drill - Decimal Inch, 296 mm Overall Length, 4XD Cutting Depth, Spiral Flute, 175 mm Flute Length, #3 Morse Taper Shank Taper Designation, 118 deg Point, Thinned Web Point, Right Hand Cutting Direction, HSS HM Cutting Edge, No Through Coolant, HSS HM, Bright/Steam Oxide, Applicable Materials: Steel, Stainless Steel, Cast Iron, Titanium, Nickel, Copper, Aluminum Magnesium, Synthetic Materials, Hard Materials and Graphite

  • Features

  • Carbide tips cuts faster than high speed steel
  • It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys
  • Bright provides a smooth, polished finish on the tool
  • It increases chip flow in softer materials such as aluminum, wood and plastic
  • Spiral flutes are constructed with a higher flute angle to remove chips more easily
  • Web-thinned
  • No coolant channel

Specifications

ApplicationFor general drilling applications
Applicable MaterialsSteel, Stainless Steel, Cast Iron, Titanium, Nickel, Copper, Aluminum Magnesium, Synthetic Materials, Hard Materials and Graphite
Cutting Depth4XD
Cutting DirectionRight Hand
Cutting Edge MaterialHSS HM
Drill Diameter Measurement SystemMetric/Imperial
Drill Size - Decimal Inch1.1811 in
Drill Size - Metric30 mm
FinishBright/Steam Oxide
Flute Length175 mm
Flute TypeSpiral
MaterialHSS HM
Overall Length296 mm
Point Angle118 deg
Point TypeThinned Web
SeriesA166
Shank Taper Designation#3 Morse Taper
Through Coolant (Yes/No)No
TypeGeneral Purpose Jobber Length

Additional Information

Standards/ApprovalDIN 345|PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov
Country of OriginFR
