Starrett LSS 424
Starrett 424 Pocket Slide Caliper/Circumference Gage, 0 to 3-1/2 in Measuring, Graduations 1/32 in, 1-3/8 in D Jaw, Hardened Stainless Steel, Satin
Invoice description:
Circumference Gage/pocke T Slide Caliper No.
Factory Order
Starrett Pocket Slide Caliper/Circumference Gage, Series: 424, 0 to 3-1/2 in Measuring, +/-0.03125 in Accuracy, Graduations: 1/32 in, 1-3/8 in Jaw Depth, Measuring System: Imperial, Hardened Stainless Steel, Satin, 5-11/64 in L x 2-5/32 in W x 19/64 in THK Dimensions
Features
- The upper edge of the slide is graduated from 0 - 11 in circumference in 16ths and the lower edge from 0 - 3-1/2 in standard measurement in 32nds
- 1-3/8 in D jaws will caliper a cylinder upto 2-3/4 in Dia
- 16ths circumference graduation
- Nib style jaw
Specifications
ApplicationFor obtaining instant circumference and diameter measurements of rope, cordage, metal rods, pipe, tubing, etc and for checking cutting speeds on lathe work
Accuracy+/-0.03125 in
Dimensions5-11/64 in L x 2-5/32 in W x 19/64 in THK
FinishSatin
Graduations1/32 in
Jaw Depth1-3/8 in
MaterialHardened Stainless Steel
Measuring Range0 to 3-1/2 in
Measuring SystemImperial
Series424
Additional Information
Country of OriginUS
Full Engineering Drawing
