Union Butterfield UTD 1700MT 10X1.5
Union Butterfield 6008880 1700M General Purpose Straight Flute Hand Tap, Right Hand Cutting, M10x1.5 Thread, D6 Thread Limit, Tapered Chamfer, 4 Flutes, Bright, HSS
Invoice description:
M10 X 1.5p 6h 1700m Hss Brt Hand Tap 6008880
In stock
(6)
Union Butterfield Straight Flute Hand Tap, General Purpose, Series: 1700M, Measurement System: Metric, Coarse, M10x1.5, Tapered Chamfer, 4 Flutes, HSS, Bright, Class of Fit: 6H, Right Hand Cutting, 1-1/4 in Thread Length, 2-15/16 in Overall Length, 0.381 in Shank Dia, Steel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials Material Application, D6 Thread Limit
Features
- The most versatile taps for hand use or machine tapping in a wide variety of materials in through or blind hole applications
- A medium alloyed high speed steel that has good machinability and good performance
- HSS exhibits hardness, toughness and wear resistance characteristics that make it attractive in a wide range of applications
Specifications
ApplicationFor through or blind hole applications
Chamfer TypeTapered
Class of Fit6H
Cutting DirectionRight Hand
Finish/CoatingBright
MaterialHSS
Material ApplicationSteel, Stainless Steel, Copper, Titanium, Nickel, Cast Iron, Aluminum Magnesium and Synthetic Materials
Measurement SystemMetric
Number of Flutes4
Overall Length2-15/16 in
Series1700M
Shank Diameter0.381 in
Thread Length1-1/4 in
Thread LimitD6
Thread SizeM10x1.5
Thread StandardCoarse
TypeGeneral Purpose
Additional Information
Standards/ApprovalANSI Specified|PROP65: This product contains chemicals known to the State of California to cause cancer. For more information: www.P65Warnings.ca.gov|CSA Approved
Country of OriginUS
