Harvey Tool HARV 16020-C3
Harvey Tool 16020-C3 Flared Corner Rounding End Mill, 0.12 in Dia Cutter, 0.02 in Length of Cut, (3) Flutes, 3/16 in Dia Shank, 2 in OAL, AlTiN
Invoice description:
Back Crem 3/16 .02r 1/2lbs 3fl
Manufacturer PN: 16020-C3
Factory Order
--Price Unavailable--
Harvey Tool, 16020-C3, Corner Rounding End Mill, Flared, 0.12 in Diameter Cutter, 2 in Overall Length, 0.02 in Length of Cut, 3 Flutes, 3/16 in Shank Diameter, Right Hand Cutting Direction, Cylindrical Shank, Solid Carbide, AlTiN
Features
- Designed to mill radius on back side of workpiece
- 5 deg flares at neck and shoulder to avoid steps
- Flares are tangent to radius (flare is blended to radius to ensure smooth form)
- Cutting on radius and flares only
- Applicable Materials are Non-Ferrous Metal, Cast Iron, Steel, Stainless Steel, Composites
- Head Diameter 0.1875 in (3/16)
- Neck Length 0.5000 in (1/2)
- Radius Center 0.0820 in
- Profile Corner Rounder
Specifications
Cutter Diameter0.12 in
Cutting DirectionRight Hand
FinishAlTiN
Length of Cut0.02 in
MaterialSolid Carbide
Number of Flutes3
Overall Length2 in
Shank Diameter3/16 in
Shank TypeCylindrical
TypeFlared
Additional Information
Standards/ApprovalPROP65: This product contains chemicals known to the State of California to cause cancer
Country of OriginUS
Sds
