Proto PRO J48018

Proto J48018 1-Piece Super Duty Drive Pin Punch, Parabolic, 1/8 in, 4-3/4 in OAL, Steel

Invoice description: Punch Pin 1/8" Super Dut Y

UPC: 662679010799
UNSPSC: 27111505
Manufacturer PN: J48018
$8.18 EA
In stock (5)
QTY:


Proto Drive Pin Punch, 1-Piece Super Duty, 1/8 in Tip, Steel Tip, 4-3/4 in Overall Length, Parabolic, Steel Handle

  • Features

  • 1-piece design for strength and durability
  • Reverse taper to help prevent binding
  • Modified parabolic striking end to help reduce mushrooming and chipping
  • Made from tool steel and specially heat treated for greater strength and durability
  • Black oxide finish to help prevent rust corrosion, extending tool life and performance
  • A polished identification panel on one of the flats is marked with the tool number and size in a black inlay
  • 5/16 in Dia striking face

Specifications

ApplicationFor greater resistance to mushrooming and chipping
Handle MaterialSteel
Overall Length4-3/4 in
Punch TypeParabolic
Tip MaterialSteel
Tip Size1/8 in
Type1-Piece Super Duty

Additional Information

Standards/ApprovalASME B107.48
Country of OriginUS
