Proto PRO J1220-T500
Proto TorquePlus J1220-T500 Anti-Slip Design Combination Wrench, Imperial, 5/8 in, 12 Points, 15 deg Offset, 9-1/2 in OAL, Alloy Steel, Full Polished, ASME B107.100
Invoice description:
Wrench Comb 5/8" 12pt Long Pattern Fp
In stock
(7)
Proto TorquePlus Combination Wrench, Anti-Slip Design, Measurement System: Imperial, 5/8 in Wrench Opening, 12 Points, 9-1/2 in Overall Length, 15 deg Offset, 1-21/64 in Open End Width, 19/64 in Open End Thickness, 15/16 in Box End Width, 13/32 in Box End Thickness, 15 deg Head, ASME B107.100 Specifications Met, 3/4 in Throat Depth, Alloy Steel, Full Polished
Features
- Full polish finish provides corrosion resistance and easy-to-clean surfaces
- 12 point box end allows for fine indexing, helping to improve speed and access
- Fits 4, 6 and 12 point fasteners
- Anti-slip design (ASD) open end
- Box ends incorporate the TorquePlus system
- Double nickel strike for rust resistance and prolonged life
- Locking groove to help prevent slippage
- Arched surface which spreads the force over a 400% larger contact area to help prolong life
- No ribs or serrations to damage fasteners
- Allows upto 15% more torque to be applied to the fastener
Specifications
ApplicationFor use on stubborn or damaged fasteners
Box End Thickness13/32 in
Box End Width15/16 in
Finish/CoatingFull Polished
Head Angle15 deg
MaterialAlloy Steel
Measurement SystemImperial
Number of Points12
Offset Angle15 deg
Open End Thickness19/64 in
Open End Width1-21/64 in
Overall Length9-1/2 in
Specifications MetASME B107.100
Throat Depth3/4 in
TypeAnti-Slip Design
Wrench Opening5/8 in
Additional Information
Standards/ApprovalASME B107.100
Country of OriginUS
