Power Team SPX 1037
Power Team 1037 MP Series Mechanical Jaw Puller, 7 ton Capacity, 2/3 Jaws, 5 in Max Reach, 10-1/2 in Max Spread
Invoice description:
2/3 Jaw Puller Manual 7 Ton Rev 2/3 Jaw Puller Manual 7ton Rev
UPC: 662536008228
UNSPSC:
27111712
Manufacturer PN: 1037
$544.58 EA
Factory Order
Estimated to ship in 7 days
Estimated to ship in 7 days
Power Team Mechanical Jaw Puller, Series: MP Series, 7 ton Capacity, 5 in Max Reach, 10-1/2 in Maximum Spread, 2/3 Jaws, 1 in Upper, 1 in Lower Jaw Width, 5/16 in Upper, 11/32 in Lower Jaw Thickness, 11/16-18 x 9 in Screw, Yes Reversible, Alloy Steel
Features
- Grip-O-Matic feature on all pullers
- The harder the pull, the tighter the grip for removing gears, bearings and countless other press fitted parts
- 2, 3 and 2/3-way combination pullers make it easy to select a specific puller for a specific application
- Forged from high quality steel, heat treated and subjected to rigorous tests which exceed rated puller capacity
- Alloy steel heads are forged for maximum strength
- Forcing screw threads are rolled, not cut, this process creates a smoother and stronger thread
- Heat treated alloy steel cross bolts for maximum shear strength
- Machined puller jaw toes produce larger and stronger pulling toes
Specifications
ApplicationFor removing gears, bearings and countless other press fitted parts
Capacity7 ton
Jaw Thickness5/16 in Upper, 11/32 in Lower
Jaw Width1 in Upper, 1 in Lower
MaterialAlloy Steel
Max Reach5 in
Maximum Spread10-1/2 in
Number of Jaws2/3
ReversibleYes
Screw Size11/16-18 x 9 in
SeriesMP Series
Additional Information
Standards/ApprovalFederal Specification GGG-P-00781-D
