GARR GARR 98500

GARR 98500 TMS Square End Mill, 1 in Dia Cutter, 4-1/4 in Length of Cut, 13 Flutes, 1 in Dia Shank, 7 in OAL, AlCrN Coated

Invoice description: Em 1x4-1/4locx1x7 1 3fl Alcrn

UNSPSC: 23242511
Manufacturer PN: 98500
$871.30 EA
Factory Order
Estimated to ship in 7 days
QTY:


GARR End Mill, Square End, Series: TMS, 1 in Diameter Cutter, 7 in Overall Length, 4-1/4 in Length of Cut, 13 Flutes, Multiple Flute, 1 in Shank Diameter, Right Hand Cutting Direction, 38 deg Helix Angle, 3-3/4 in Shank Length, Solid Submicron Carbide, AlCrN Coated

  • Features

  • Engineered for titanium
  • Multiple flutes for increased feed rates
  • Odd number of flutes to naturally break up harmonics
  • Effective for Trochoidal milling
  • Up to 5% Radial (ap) engagement
  • Can be used to finish most steels under 40Rc, as well as aluminum
  • Conventional grind for better finish cutting and less push off
  • Regrindable
  • Finisher for titanium

Specifications

ApplicationFor finishing operations
Cutter Diameter1 in
Cutting DirectionRight Hand
FinishAlCrN Coated
Flute TypeMultiple
Helix Angle38 deg
Length of Cut4-1/4 in
MaterialSolid Submicron Carbide
Number of Flutes13
Overall Length7 in
SeriesTMS
Shank Diameter1 in
Shank Length3-3/4 in
TypeSquare End

Additional Information

Country of OriginUS
