Tiger WEI 58073

Tiger 58073 Performance Line Depressed Center Grinding Wheel, 5 in Dia x 1/4 in THK, 7/8 in Center Hole, 24 Grit, Zirconia Alumina Abrasive

Invoice description: 5" X 1/4" Tiger Zirc Typ E 27 Grinding Wheel,

UNSPSC: 31191600
Manufacturer PN: 58073
$8.62 EA
Factory Order
Estimated to ship in 14 days
QTY:


Tiger Depressed Center Grinding Wheel, Performance Line, 5 in Wheel Diameter, 1/4 in Wheel Thickness, 7/8 in Center Hole, Arbor Connector, 24 Grit, Coarse Grade, Zirconia Alumina Abrasive, Wheel Type Number: Type 27, 12200 rpm Maximum, Resin Bond, Applicable Materials: Carbon Steel, Structural Steel, Cast Iron, Steel and Stainless Steel, Wheel Hardness: T, Yes Reinforced, Specifications Met: ANSI B7.1-2010

  • Features

  • Type 27 grinding wheels are designed with fiberglass cut back from the edge to provide instant aggressive grinding on new wheels
  • High performance wheels leverage a self-sharping zirconia alumina grain that delivers fast, consistent grinding on steel and stainless steel
  • All wheels are ceramic infused for that extra surge in performance
  • Self-sharpening zirconia grain retains high cutting performance through the life of the wheel
  • Performance line - Weiler Abrasives Tiger wheels deliver the right combination of performance and value
  • This versatile line-up offers a long life solution for all your general purpose applications
  • Type 27 - flat profile with depressed center allows for a wide range of grinding angles (0 to 45)
  • Ceramic infused for faster, longer grinding

Specifications

ApplicationHeavy Stock Removal, Scale Removal, Weld Removal, Weld Blending, Edge Beveling, Torch-Cut Softening, Cutting and Parting, Notching and Rough Grinding
Abrasive MaterialZirconia Alumina
Applicable MaterialsCarbon Steel, Structural Steel, Cast Iron, Steel and Stainless Steel
Bond TypeResin
Center Hole Size7/8 in
Connector TypeArbor
GradeCoarse
Grit24
Maximum Speed12200 rpm
ReinforcedYes
Specifications MetANSI B7.1-2010
TypePerformance Line
Wheel Diameter5 in
Wheel HardnessT
Wheel Thickness1/4 in
Wheel Type NumberType 27

Additional Information

Standards/ApprovalANSI B7.1-2010
Country of OriginSI

Documents
