GARR GARR 52894
GARR 52894 255MC Center Cutting High Performance End Mill, 1 in Dia Cutter, 1-1/8 in Length of Cut, 5 Flutes, 1 in Dia Shank, 4 in OAL, TiCN Coated
Invoice description:
Em 1x1-1/8locx1x4 5fl Ticn Hp
Factory Order
GARR High Performance End Mill, Center Cutting, Series: 255MC, 1 in Diameter Cutter, 4 in Overall Length, 1-1/8 in Length of Cut, 5 Flutes, Spiral Flute, 1 in Shank Diameter, Right Hand Cutting Direction, 45 deg Helix Angle, 2-7/8 in Shank Length, Solid Submicron Carbide, TiCN Coated
Features
- High performance milling in steels, stainless steel and exotics
- Rigid work holding, machine stability and part integrity are critical
- Coated provides improved abrasion resistance lubricity
- Up to 25% faster than uncoated
- Improved finishes in titanium
- Heavy core
- Sharp corners
Specifications
Cutter Diameter1 in
Cutting DirectionRight Hand
FinishTiCN Coated
Flute TypeSpiral
Helix Angle45 deg
Length of Cut1-1/8 in
MaterialSolid Submicron Carbide
Number of Flutes5
Overall Length4 in
Series255MC
Shank Diameter1 in
Shank Length2-7/8 in
TypeCenter Cutting
Additional Information
Country of OriginUS
