Midland Industries MIDM 28239
Midland Industries 28239 90 deg Street Elbow, 1/4 in Nominal, MNPT x FNPT End Style, Brass
Invoice description:
Elbow 1/4 Mipxfip Fg 45 Str
Factory Order
Midland Industries Street Elbow, Fitting/Connector Type: 90 deg Elbow, 1/4 in Nominal, MNPT x FNPT, 1200 psi, Forged, Brass, -65 to 250 deg F, 0.63 x 1.06 in
Features
- Fair resistance vibration
- Used with brass, bronze, copper, steel, aluminum and iron pipe
- /- 0.02 tolerance on all dimensions
- 1/4-18 thread size
- 0.81 in wrench flat
Specifications
ApplicationFor grease, fuels, LP and natural Gas (available on special order), refrigeration, instrumentation and hydraulic systems
Dimensions0.63 x 1.06 in
End StyleMNPT x FNPT
Fitting/Connector Type90 deg Elbow
MaterialBrass
Method of ManufactureForged
Nominal Size1/4 in
Pressure Rating1200 psi
Temperature Rating-65 to 250 deg F
Additional Information
Standards/ApprovalASA Certified|ASME Specified|SAE Approved
Country of OriginUS
