Iscar ISCAR 6403199
Iscar 6403199 CUT-GRIP Double End Grooving Insert, Rectangle Shape, GEPI Insert, 239015 Insert, Neutral Cutting, 2.39 mm W Cutting, Manufacturers Grade: IC908, PVD-TiAlN Coated, Material Grade: H, K, M, P, S
Invoice description:
Gepi 2.39-0.15 Ic908
Factory Order
Iscar Grooving Insert, Double End, Series: CUT-GRIP, GEPI Insert, 239015 Insert, Rectangle Shape, 2.39 mm Cutting Width, 1 mm Maximum Depth of Cut, 0.15 mm Corner Radius, 2.39 mm Width, 10 mm Length, Manufacturers Grade: IC908, ISO Code: GEPI 2.39-0.15 IC908, Neutral Cutting Direction, Carbide, PVD-TiAlN Coated, Material Grade: H, K, M, P, S
Features
- For internal grooving at low feeds in diameters from 11.5 mm
Specifications
ApplicationExternal Grooving, External Grooving and Turning, Groove Turning, Internal Grooving and Internal Grooving and Turning
Corner Radius0.15 mm
Cutting DirectionNeutral
Cutting Width2.39 mm
FinishPVD-TiAlN Coated
Insert Size239015
Insert StyleGEPI
ISO CodeGEPI 2.39-0.15 IC908
Length10 mm
Manufacturers GradeIC908
MaterialCarbide
Material GradeH, K, M, P, S
Maximum Depth of Cut1 mm
SeriesCUT-GRIP
ShapeRectangle
TypeDouble End
Width2.39 mm
Additional Information
Country of OriginIS
