Iscar ISCAR 6200227
Iscar 6200227 HELIFACE Double End Utility Grooving Insert, Rectangle Shape, HGPL Insert, 3002 Insert, Neutral Cutting, 3 mm W Cutting, Manufacturers Grade: IC08, Uncoated, Material Grade: N
Invoice description:
Hgpl 3002y Ic08
Factory Order
Iscar Grooving Insert, Double End Utility, Series: HELIFACE, HGPL Insert, 3002 Insert, Rectangle Shape, 3 mm Cutting Width, 1.8 mm Maximum Depth of Cut, Y Chipbreaker, 0.2 mm Corner Radius, 3 mm Width, 19 mm Length, Manufacturers Grade: IC08, ISO Code: HGPL 3002Y IC08, Neutral Cutting Direction, Carbide, Uncoated, Material Grade: N
Specifications
ApplicationExternal Grooving, Parting and Face Machining
ChipbreakerY
Corner Radius0.2 mm
Cutting DirectionNeutral
Cutting Width3 mm
FinishUncoated
Insert Size3002
Insert StyleHGPL
ISO CodeHGPL 3002Y IC08
Length19 mm
Manufacturers GradeIC08
MaterialCarbide
Material GradeN
Maximum Depth of Cut1.8 mm
SeriesHELIFACE
ShapeRectangle
TypeDouble End Utility
Width3 mm
Additional Information
Country of OriginIL
