Iscar ISCAR 6200081
Iscar 6200081 HELIFACE Double End Utility Grooving Insert, Rectangle Shape, HFPL Insert, 6004 Insert, Left Hand Cutting, 6 mm W Cutting, Manufacturers Grade: IC354, PVD-TiCN Coated, Material Grade: M, P
Invoice description:
Hfpl 6004 Ic354
Factory Order
Iscar Grooving Insert, Double End Utility, Series: HELIFACE, HFPL Insert, 6004 Insert, Rectangle Shape, 6 mm Cutting Width, 3 mm Maximum Depth of Cut, 0 deg Lead Angle, 0.4 mm Corner Radius, 6 mm Width, 19 mm Length, Manufacturers Grade: IC354, ISO Code: HFPL 6004 IC354, Left Hand Cutting Direction, Carbide, PVD-TiCN Coated, Material Grade: M, P
Specifications
ApplicationFace Grooving, Face Grooving and Turning, Face Grooving Along Shaft, Groove Turning, Internal Face Grooving, Face Machining and Internal Face Recessing
Corner Radius0.4 mm
Cutting DirectionLeft Hand
Cutting Width6 mm
FinishPVD-TiCN Coated
Insert Size6004
Insert StyleHFPL
ISO CodeHFPL 6004 IC354
Lead Angle0 deg
Length19 mm
Manufacturers GradeIC354
MaterialCarbide
Material GradeM, P
Maximum Depth of Cut3 mm
SeriesHELIFACE
ShapeRectangle
TypeDouble End Utility
Width6 mm
Additional Information
Country of OriginIL
