Iscar ISCAR 6003124
Iscar 6003124 PENTACUT External Full Radius Grooving Insert, Pentagon Shape, PENTA Insert, 24 Insert, Neutral Cutting, 2.39 mm W Cutting, Manufacturers Grade: IC908, PVD-TiAlN Coated, Material Grade: H, K, M, P, S
Invoice description:
Penta 24n239j120 Ic908 Groove-turn Insert
Pack Size: 5
UNSPSC:
23242107
Manufacturer PN: 6003124
$72.50 EA
Factory OrderEstimated to ship in 14 days
Iscar Grooving Insert, External Full Radius, Series: PENTACUT, PENTA Insert, 24 Insert, Pentagon, 2.39 mm Cutting Width, 5 mm Maximum Depth of Cut, J Chipbreaker, 1.2 mm Corner Radius, 2.39 mm Width, Manufacturers Grade: IC908, ISO Code: PENTA 24N239J120 IC908, Neutral Cutting, Carbide, PVD-TiAlN Coated, Material Grade: H, K, M, P, S
Features
- A combination of very rigid clamping system and a strong insert design enables machining at very high machining parameters
- Easy and fast edge indexing from either side of the holder
- Multi-corner, five cutting edges that provide the most advantageous price per cutting edge
- Precision grooving most economical inserts with 5 cutting edges for soft parts, minimize burr size
Specifications
ApplicationExternal Grooving and Groove Turning
ChipbreakerJ
Corner Radius1.2 mm
Cutting DirectionNeutral
Cutting Width2.39 mm
FinishPVD-TiAlN Coated
Insert Size24
Insert StylePENTA
ISO CodePENTA 24N239J120 IC908
Manufacturers GradeIC908
MaterialCarbide
Material GradeH, K, M, P, S
Maximum Depth of Cut5 mm
SeriesPENTACUT
ShapePentagon
TypeExternal Full Radius
Width2.39 mm
Additional Information
Country of OriginIS
