Iscar ISCAR 5680609
Iscar 5680609 HELITANG T490 LINE Milling Insert With 4 Helical Cutting Edges, LNHT Insert, 130612 Insert, Carbide, Manufacturers Grade: IC810, Rectangle Shape, Material Grade: K, P
Invoice description:
T490 Lnht 130612pntr 810
Factory Order
Iscar Milling Insert, Series: HELITANG T490 LINE, LNHT Insert, 130612 Insert, Rectangle Shape, 13 mm Thickness, 6.65 mm Width, 13.81 mm Length, PNTR Chipbreaker, 1.2 mm Corner Radius, Manufacturers Grade: IC810, ISO Code: T490 LNHT 130612PNTR IC810, Right Hand of Insert, Carbide, PVD-AlTiN+TiN Coated, Material Grade: K, P, Steel, Stainless Steel Ferritic and Martensitic, Stainless Steel Austenitic and Duplex and High Temperature Alloys Material Application
Specifications
ApplicationFacing, Bottom Shouldering, Shouldering, Rampdown, Side Slotting, Slanted Shoulder and Chamfer and Slotting
ChipbreakerPNTR
Corner Radius1.2 mm
FinishPVD-AlTiN+TiN Coated
Hand of InsertRight
Insert Size130612
Insert StyleLNHT
ISO CodeT490 LNHT 130612PNTR IC810
Length13.81 mm
Manufacturers GradeIC810
MaterialCarbide
Material ApplicationSteel, Stainless Steel Ferritic and Martensitic, Stainless Steel Austenitic and Duplex and High Temperature Alloys
Material GradeK, P
SeriesHELITANG T490 LINE
ShapeRectangle
Thickness13 mm
Width6.65 mm
Additional Information
Country of OriginIL
