Iscar ISCAR 5607269

Iscar 5607269 HELITANG T490 LINE Single Sided Milling Insert With 4 Helical Cutting Edges, LNMT Insert, 130631 Insert, Carbide, Manufacturers Grade: IC830, Rectangle Shape, Material Grade: M, P, S

UNSPSC: 23242107
Manufacturer PN: 5607269
$36.50 EA
Factory Order
Estimated to ship in 14 days
QTY:


Iscar Milling Insert, Single Sided, Series: HELITANG T490 LINE, LNMT Insert, 130631 Insert, Rectangle Shape, 12.45 mm Thickness, 6.65 mm Width, 13.75 mm Length, PNTR Chipbreaker, 3.1 mm Corner Radius, Positive Rake, Manufacturers Grade: IC830, ISO Code: T490 LNMT 130631PNTR IC830, Right Hand of Insert, Carbide, PVD-TiAlN/AlTiN+TiN Coated, Material Grade: M, P, S, Steel, Stainless Steel Ferritic and Martensitic, Stainless Steel Austenitic and Duplex and High Temperature Alloys Material Application

Specifications

ApplicationFacing, Bottom Shouldering, Shouldering, Rampdown, Side Slotting, Slanted Shoulder and Chamfer and Slotting
ChipbreakerPNTR
Corner Radius3.1 mm
FinishPVD-TiAlN/AlTiN+TiN Coated
Hand of InsertRight
Insert Size130631
Insert StyleLNMT
ISO CodeT490 LNMT 130631PNTR IC830
Length13.75 mm
Manufacturers GradeIC830
MaterialCarbide
Material ApplicationSteel, Stainless Steel Ferritic and Martensitic, Stainless Steel Austenitic and Duplex and High Temperature Alloys
Material GradeM, P, S
RakePositive
SeriesHELITANG T490 LINE
ShapeRectangle
Thickness12.45 mm
TypeSingle Sided
Width6.65 mm
